Timco M6 Hex Flanged Masonry Bolts

Price range: £21.86 through £48.52 Inc Vat.

This stress free, non-expansion through fixing is the new solution for heavy duty anchoring into concrete, brick, stone, wood and concrete block replacing the need for traditional anchors such as throughbolts, shield, sleeve and drop-in anchors.

• Designed to replace traditional expansion anchors
• TIMCO micro plating technology gives a higher resistance to corrosion and enhances speed of installation
• High-Low parallel threads for ease of insertion and high pull-out values
• Removable & adjustable non-expansion through fixing
• Unique concave thread configuration
• All steel, non-flammable fixing conforming to BS 7671 standard’s 18th edition, which requires wiring systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire.

SKU: MF6 Category: Brand:

Technical Data

Concrete ≥25N/mm2
Drill Hole Ø (mm) 6.0
Min. Embed. Depth (mm) 30
Min. Drill Hole Depth (mm) 40
Rec. Tensile Load (kN) 2.44
Max. Rec. Load (kg) 244
Min. Over-Drill for Dust (mm) 10
Min. Centre Spacing (mm) 90
Min. Edge Distance (mm) 45
Min. Structure Thickness (mm) 60
Fletton Brick 30N/mm2
Drill Hole Ø (mm) 6.0
Min. Embed. Depth (mm) 30
Min. Drill Hole Depth (mm) 40
Rec. Tensile Load (kN) 2.28
Max. Rec. Load (kg) 228
Min. Over-Drill for Dust (mm) 10
Min. Centre Spacing (mm)
Min. Edge Distance (mm)
Min. Structure Thickness (mm)
Cheshire Brick 45N/mm2
Drill Hole Ø (mm) 6.0
Min. Embed. Depth (mm) 30
Min. Drill Hole Depth (mm) 40
Rec. Tensile Load (kN) 1.36
Max. Rec. Load (kg) 136
Min. Over-Drill for Dust (mm) 10
Min. Centre Spacing (mm)
Min. Edge Distance (mm)
Min. Structure Thickness (mm)
Class B Eng. Brick 75N/mm2
Min. Embed. Depth (mm) 30
Min. Drill Hole Depth (mm) 40
Rec. Tensile Load (kN) 3.49
Max. Rec. Load (kg) 349
Min. Over-Drill for Dust (mm) 10
Min. Centre Spacing (mm)
Min. Edge Distance (mm)
Min. Structure Thickness (mm)
Class B Eng. Brick 75N/mm2
Drill Hole Ø (mm) 6.0

Additional information

Weight N/A
Pack Type

Box

MOQ

1

Finish

Exterior (Silver Organic)

Corrosion Rating (1-5)

3 – Urban & industrial areas with a low salt atmosphere

Point Type

Chamfered

Thread Type

High-Low Parallel

Head Type

Hex Flange

Driver Bit Size

10mm Socket

Thread Ø (mm)

6mm

Drill Hole Ø (mm)

6mm

Fixture Hole Size Ø (mm)

8mm

Substrates

Block, Brick, Concrete, Stone, Wood

Approval

BS 7671:2018

Brand

TIMCO
